APV-1000-01 For insulin glargine (300 units/mL)

Digital Injector 1.5 mL Cartridge Type

Features

  • 400 times Injection Histories can be stored in Injector
  • Compliant with ISO 11698-1: 2014
  • Guidance for next step by LCD
  • Reminder Message by LCD
  • Built-in temperature sensor

Specifications

Power source Internal power device: 3 VDC (Dry cell: CR123A/CE17345)
Shape and dimensions(WxHxD) Digital Injector 47 mm (1.85") x 145 mm (5.71") x 27 mm (1.06")
* Excluding projections
Pouch 97 mm (3.82") x 168 mm (6.61") x 45 mm (1.77")
Weight Digital Injector 155g (0.34 lbs.) * Including battery (17 g)
Pouch Approx. 50 g (0.11 lbs.)
Environmental conditions during usage of injector (after unpacking) Temperature 0°C to 37°C (32°F to 99 °F)
(Do not freeze.)
Humidity 20 % RH to 80 % RH
Atmosspheric pressure 700 hPa to 1060 hPa
Environmental conditions during transport and storage (Packaged state) Temperature -5°C to 45°C (23°F to 113 °F)
Humidity 10 % RH to 80 % RH
(Do not condensate.)
Dose range per injection 1 unit to 80 units
Increments 1 unit
Dose accuracy Compliant with ISO11608-1:2014

Catalog Download
