Purpose-Built Cold Chain Storage
PHCbi brand pharmaceutical refrigerators are engineered from the inside out to create, maintain, and restore precise temperatures necessary for vaccine storage. Our purpose-built pharmaceutical refrigerators are designed for temperature uniformity and stability that is not commonly found with household or commercial cabinets. PHCbi brand pharmacy refrigerators satisfy current and evolving storage protocols essential for vaccine cold chain storage.
Ultimate Sample Protection
TwinGuard dual cooling ensures stable in-chamber temperature with twice the sample protection for double the peace of mind. Dual independent refrigerating circuits are housed within a single unit. In the event of a malfunction in one circuit, the second circuit seamlessly takes over, steadfastly sustaining the in-chamber temperature at SV 5°C (±3°C).* This dual safety feature acts as a fail-safe mechanism, providing enhanced security for the preservation of vital stored items.
*Factory 9-point temperature testing in AT +23°C
Superior Temperature Uniformity
The cutting-edge refrigeration system ensures reliable, uniform temperature control. Natural HC refrigerants and state of the art inverter-controlled compressors achieve significant reduction in power consumption and greater uniformity than predecessor models.i In-chamber temperature control adapts to ambient temperature through an intelligent compressor control mechanism. This ensures energy efficiency while maintaining optimal performance based on environmental conditions.
Ergonomic Design
TwinGuard ECO Series refrigerators are designed for ergonomic use and enable a clear view of stored items through the large glass panels. The slim profile, space-saving design also allows for quick retrieval of all products and requires less installation space.
Enhanced Condensation Mitigation
The thermal, double-pane sliding glass door with Low-E coating is thoughtfully engineered to enhance energy efficiency, shield stored items from heat transfer through the window, and prevent moisture formation on the glass surface.
A top-mounted heater and warm air emitted from the air vents near the sliding glass door rail complement the door design to provide enhanced condensation mitigation on the glass surface. The meticulous design ensures optimal preservation conditions and contributes to the overall performance of the refrigeration system.
OLED Control Panel & Microprocessor Controller
The PHCbi microprocessor includes comprehensive setpoint, alarms, monitoring, and diagnostic functions. The microprocessor and the electronic temperature controls ensure the set temperature is maintained.
The microprocessor controller and OLED display ensure intuitive use, seamlessly enhancing visibility and operation. Conveniently manage temperatures in precise 0.1°C increments. Minimum and maximum temperatures are easily accessed for 12 or 24 hours.
Safe & Secure Storage
Standard features include adjustable audible and visual alarms, providing a flexible alert system tailored to your needs. The password protected control panel provides security. Alarm conditions are promptly displayed and meticulously recorded for USB data retrieval.
Energy Efficient
Natural HC refrigerants, inverter-controlled compressors, and a new Cycle-Defrost system combine to improve in-chamber temperature control. Peak-to-peak measurements at 9 positions inside the chamber indicate temperature distribution within 2°C to 8°C
i Based upon PHCNA internal data.
